Showing 20593 results

Scale: ‘½ scale’
Sketches of proposed memorial ‘to be erected by Mr. Geary’ in the Church of St. Francis. Three alternative sketches or ‘schemes’ of the memorial statue or shrine to Our Lady are given by John J. Robinson & R.C. Keefe, architects, 8 Merrion Square, Dublin. With manuscript annotations re the costs of the work and installation.

Scale: ‘1/8 scale’
Sketch plans (with sections) of proposed schemes for alterations to the sacristy of the Church of St. Francis, Kilkenny, by John J. Robinson & R.C. Keefe, architects, 8 Merrion Square, Dublin. The sacristy is bordered by reception rooms, altar servers’ rooms, confessionals and a vestments’ press. See related correspondence at CA KK/2/4/16.

Scale: ‘1/8 inch’.
Side elevation of proposed alterations to the exterior of the Church of St. Francis by John J. Robinson & R.C. Keefe, architects, 8 Merrion Square, Dublin.

Scale: ¼ inch to 1 foot for plan; 5ft to 1 mile for site map
Plan sheet for internal alterations at the Capuchin Friary, Kilkenny, to accommodate the novitiate building. Plan by Sylvester Bourke, architect, 79 High Street, Kilkenny. The novitiate is situated between the Friary and the Church of St. Francis. Includes plan and sections of bedrooms, the recreation hall and the study hall. With a site map insert showing the Friary bounded by Walkin (Friary) Street and Pennyfeather Lane. Sheet number: LO.14 a/1. See also CA KK/2/4/25.

Scale: ¼ inch to 1 foot
Technical plan for choir room accommodation and ventilation at the Capuchin Friary, Kilkenny by Sylvester Bourke, architect, 79 High Street, Kilkenny. The drawing was supplied to the guardian of the Kilkenny Friary. Sheet number: LO.14 (A). Includes sections and elevations of choir ceiling, installations (kneelers) and second floor plan. It is noted that ‘the treatment of the arms of the Capuchin Order as incorporated in the extract grid is to special detail and template and will be supplied as necessary’.

Specifications and estimates for the installation of electric lighting in the Capuchin Friary and Church, Kilkenny, by Keatinge & Gaule, electrical engineers and contractors, 126 The Quay, Waterford, and Louis J. Lawless, consulting engineers, 19 Percy Place, Dublin.

Specification by John J. Robinson & R.C. Keeffe, architects, 8 Merrion Square, Dublin, of work to be done and materials to be used in the carrying out of the proposed new aisle, porches, and extension to the nave at the Capuchin Friary, Kilkenny.
